Premier all-in-one video bar for small to medium rooms.

Rally Bar Mini, Graphite or White, Video Bar, 4K, 4x zoom, PTZ, all-in-one design from huddle/sm. rooms. Includes: Rally Bar Mini w/stand.

SEE WHAT YOU’VE BEEN MISSING

With a dual-camera system and RightSight 2 auto-framing technology, Rally Bar Mini brings remote participants into the conversation. Choose Speaker View to highlight the active speaker, Group View to capture everyone in the room, or combine the two for an immersive and engaging experience.

LOOKS TRUE-TO-LIFE

An innovative dual-camera system with optical zoom and an AI Viewfinder delivers fluid, cinematic video in small and medium rooms.

SOUNDS AWESOME

Rally Bar Mini’s advanced audio engineering delivers rich, natural sound and makes sure every voice is clearly heard.

GREAT CONVERSATIONS START HERE

AI Sound Optimization

Auto-level loud and soft voices – while suppressing unwanted noise – with AI-based RightSound technology that improves over time.

Adaptive Beamforming

Focus on the active talker with high-precision beamforming mics.

EXPAND THE CONVERSATION

Easily accommodate any small to medium room or huddle space, starting with a 15 ft (4.6 m) mic pickup range (varies by environment) and the option to add up to 2 Rally mic pods.

WORKS WITH YOUR PREFERRED PLATFORM

Start your meeting with just one touch, seamlessly connecting Rally Bar Mini to your preconfigured room solution.

DESIGNED FOR DEPLOYMENT AT SCALE

Appliance Mode

Run supported video conferencing applications – such as Zoom^®, Microsoft Teams^®, and others – directly on the device with no computer or laptop required.

USB Mode

Connect via USB to virtually any PC or Mac with no additional software needed.

Cable Management

Ensure clean, confident installs with secure cable retention and minimal cabling.

Mounting Options

Take advantage of multiple mounting options to deploy Rally Bar Mini quickly and easily across all your small meeting rooms.

SIMPLE TO MANAGE

Easily manage your Logitech video collaboration devices with Logitech Sync. Monitor room health, deploy updates, and modify settings all from a single cloud-based platform. And with Sync Insights, you can see how meeting spaces are utilized over time.

Insights

Monitoring

Management

COMPARISON

Specs & Details

DIMENSIONS

Height: 3.6 in (91.4 mm)
Width: 2.36 ft (719 mm)
Depth: 3.98 in (101 mm)
Lens Depth: 0.73 in (18.5 mm)
Weight: 8.88 lbs (4.03)

SYSTEM REQUIREMENTS

Internet Connection: Wired or wireless
USB Mode: Windows® 10 or later, the two most recent versions of macOS
Appliance Mode: Room solution software license (not included).

TECHNICAL SPECIFICATIONS

Certifications & Compatibility

Certifications
- Microsoft Teams Rooms on Android™ 5
- Microsoft Teams Rooms on Windows® 6
- Zoom Room™
- Tencent Meeting Rooms
Appliance Mode: Supports compatible video conferencing software in appliance mode (no PC required), including
- Microsoft Teams Rooms on Android™
- Zoom Room™
- GoToRoom®
- Pexip Room
- RingCentral Rooms™
USB Mode: Plug-and-play USB connectivity with virtually any video conferencing application
For the latest information on certifications and compatibility, visit www.logitech.com/support/vc-certifications.

GENERAL SPECIFICATIONS

Built-in Components: 6 beamforming microphones, PTZ camera, 3 speakers, AI Viewfinder, cable management & retention system, table stand, Logitech CollabOS platform
Enclosure: All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference
Device Management: Logitech Sync
Displays Supported: 2
Display Resolution: Up to 1080p
Network Protocol Support: IPv4, IPv6
Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file

Camera

Resolution: 0.71 in (18 mm) key pitch
Pan: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 4X HD digital zoom
Diagonal Field of View: 120°
Horizontal Field of View: 113°
Vertical Field of View: 80.7°
Total Room Coverage (field of view + pan and tilt): 163° horizontal x 110° vertical

Woofer Speaker

Driver: 2.7 in (70 mm)
Sensitivity: 92 dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ½ meter
Rated Power: 8W
THD: 1kHz <2% at 1W
Speaker Sampling Rate: 48KHz
Impedance: 4 Ohms

Midrange Speakers

Drivers: 0.08 x 1.69in (2x 43 mm)
Sensitivity: 84 dB SPL @ 1W/1M
Rated Power: 4W
THD: 1kHz <2% at 1W
Speaker Sampling Rate: 48KHz
Impedance: 4 Ohms

Microphones

Frequency Response: 90Hz – 16kHz
Sensitivity: >-36dBFS +/-1 dB @ 1Pa
Microphone data rate output: 48 kHz
Pickup Range: 15 ft / 4.5m
Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
Noise suppression: AI based de-noising algorithm
Add-on Mics: Supports up to 2 additional Rally Mic Pods

RightSense™ Technologies

RightLight™: Renders natural skin tones for each participant
RightSight: Primary camera frames the active speaker while the AI Viewfinder captures everyone in the room
RightSound: Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo

Interfaces

HDMI Out: 2 (up to 1080p)
HDMI In: 1
USB: 3x Type A, 1x Type C
Network: 10/100/1G Ethernet
WiFi: 802.11a/b/g/n/ac
External Mic Input: Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable)
Remote Control: Bluetooth® Low Energy

Power & Cables

Power supply: Auto-sensing
Operating Voltage/Power: 100-240V, 19V, 4.74A
Power Supply Dimensions: 5 in (127 mm) x 2.01 in (51 mm) x 1.18 in (30 mm)
DC Cable: 5 ft (1.5 m)
AC Cable: 4.9 ft (1 m)
HDMI 1.4 Cable: 6.5 ft (2 m)
USB A to USB C 3.0 Cable: 7.2 ft (2.2 m)

Environmental

Operating Temperature: 0 to 40°C
Storage Temperature: -40 to 70°C
Humidity: 10 to 95%
BTU/hr: 57 idle, 64 in meeting

Security

Full Disk Encryption: AES-128
Data Encryption: Symmetric Keys, PKI
Device Identity: Protected by device attestation
Device Access: Authenticated using API
Key Protection: Arm TrustZone, RPMP

PACKAGE CONTENTS

Rally Bar Mini
Power supply
AC power cord
HDMI cable
USB cable
Remote control
Lens caps for main lens and AI Viewfinder
User documentation

WARRANTY INFORMATION

Standard: 2-year limited hardware warranty included.
Extended: Additional one-year and three-year extended warranties available at the time of hardware purchase.
Contact your reseller for availability.
